Hewlett Packard Enterprise ProCurve 3500-48 44x10 100+4dp

Forsiden / Kommunikation / Switche / Hewlett Packard Enterprise ProCurve 3500-48 44x10 100+4dp

Hewlett Packard Enterprise ProCurve 3500-48 44x10 100+4dp

Varenummer: J9472A

The 3500 series includes 24-port and 48-port stackables

Produkt Administreret
Porte 44
Hastighed 1Gbps

16.893,-
21.116,25 inkl. moms

Ikke på lager

Kontakt mig, når varen er på lager

Antal:

The ProCurve 3500yl Switch series consists of the most advanced intelligent edge switches in the ProCurve Networking product line.

Overholdelse af branchestandarder
Elektromagnetisk kompatibilitet	FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
Immunitetsstandard	EN 55024, CISPR 24; IEC 61000-4-2; 4 kV CD, 8 kV AD; IEC 61000-4-3; 3 V/m; IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line); IEC 61000-4-5; 1 kV/2 kV AC; IEC 61000-4-6; 3 V; IEC 61000-4-8; 1 A/m, 50 or 60 Hz; IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25 periods; EN 61000-3-2, IEC 61000-3-2; EN 61000-3-3, IEC 61000-3-3
Overholdelse af branchestandarder	EN: EN 55024, CISPR 24; ESD: IEC 61000-4-2; 4 kV CD, 8 kV AD; Radiated: IEC 61000-4-3; 3 V/m; EFT/Burst: IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line); Surge: IEC 61000-4-5; 1 kV/2 kV AC; Conducted: IEC 61000-4-6; 3 V; Power frequency magnetic field: IEC 61000-4-8; 1 A/m, 50 or 60 Hz; Voltage dips and interruptions: IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25 periods; Harmonics: EN 61000-3-2, IEC 61000-3-2; Flicker: EN 61000-3-3, IEC 61000-3-3
Sikkerhed	EN 60950/IEC 60950; CAN/CSA 22.2 No. 60950; UL 60950; IEC 60950
Lydtryk (standby)
Lydtryk	Power: 55.8 dB, Pressure: 43.5 dB, ISO 7779, ISO 9296
Driftshøjde	up to 4.6 km
Luftfugtighed ved drift	15 to 95% @ 104°F (40°C) (noncondensing)
Luftfugtighed ved opbevaring	15 to 95% @ 149°F (65°C) (noncondensing)
Driftstemperaturinterval	0 to 55°C
Temperaturområde ved opbevaring	-40 to 70°C
Adaptertilslutning
Varmeafgivelse	465 BTU/hr (490.58 kJ/hr)
Routing-tabel størrelse	10000 entries
Routing/switching kapacitet	16.8 Gb/s
Størrelse på adressetabel	64000 entries
Administrationsfunktioner	HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (serial RS-232C)
Kommunikation	RFC 1591 DNS (client); HTML and telnet management; IEEE 802.1ad Q-in-Q (Premium License); IEEE 802.1D MAC Bridges; IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.1s Multiple Spanning Trees; IEEE 802.1v VLAN classification by Protocol and Port; IEEE 802.1w Rapid Reconfiguration of Spanning Tree; IEEE 802.3ad Link Aggregation Control Protocol (LACP); IEEE 802.3af Power over Ethernet; IEEE 802.3x Flow Control; RFC 768 UDP; RFC 783 TFTP Protocol (revision 2); RFC 792 ICMP; RFC 793 TCP; UDLD (Uni-directional Link Detection); RFC 826 ARP; RFC 854 TELNET; RFC 868 Time Protocol; RFC 951 BOOTP; RFC 1058 RIPv1; RFC 1350 TFTP Protocol (revision 2); RFC 1519 CIDR; RFC 1542 BOOTP Extensions; RFC 2030 Simple Network Time Protocol (SNTP) v4; RFC 2131 DHCP; RFC 2453 RIPv2; RFC 2548 (MS-RAS-Vendor only); RFC 3046 DHCP Relay Agent Information Option; RFC 3576 Ext to RADIUS (CoA only); RFC 3768 VRRP (Premium License); RFC 4675 RADIUS VLAN & Priority; RFC 3376 IGMPv3 (host joins only); RFC 3973 Draft 2 PIM Dense Mode (Premium License); RFC 4601 Draft 10 PIM Sparse Mode (Premium License); RFC 1981 IPv6 Path MTU Discovery; RFC 2460 IPv6 Specification; RFC 2710 Multicast Listener Discovery (MLD) for IPv6; RFC 2925 Remote Operations MIB (Ping only); RFC 3019 MLDv1 MIB; RFC 3315 DHCPv6 (client only); RFC 3513 IPv6 Addressing Architecture; RFC 3596 DNS Extension for IPv6; RFC 3810 MLDv2 (host joins only); RFC 4022 MIB for TCP; RFC 4113 MIB for UDP; RFC 4251 SSHv6 Architecture; RFC 4252 SSHv6 Authentication; RFC 4253 SSHv6 Transport Layer; RFC 4254 SSHv6 Connection; RFC 4293 MIB for IP; RFC 4419 Key Exchange for SSH; RFC 4443 ICMPv6; RFC 4541IGMP & MLD Snooping Switch; RFC 4861 IPv6 Neighbor Discovery RFC 4862 IPv6 Stateless Address Auto-configuration; RFC 1213 MIB II; RFC 1493 Bridge MIB; RFC 1724 RIPv2 MIB; RFC 1850 OSPFv2 MIB; RFC 2021 RMONv2 MIB; RFC 2096 IP Forwarding Table MIB; RFC 2613 SMON MIB; RFC 2618 RADIUS Client MIB; RFC 2620 RADIUS Accounting MIB; RFC 2665 Ethernet-Like-MIB; RFC 2668 802.3 MAU MIB; RFC 2674 802.1p and IEEE 802.1Q Bridge MIB; RFC 2737 Entity MIB (Version 2); RFC 2787 VRRP MIB; RFC 2863 The Interfaces Group MIB; RFC 2925 Ping MIB; RFC 2328 OSPFv2 (Premium License); RFC 3101 OSPF NSSA; RFC 2474 DiffServ Precedence, including 8 queues/port; RFC 2597 DiffServ Assured Forwarding (AF); RFC 2598 DiffServ Expedited Forwarding (EF); IEEE 802.1X Port Based Network Access Control; RFC 1492 TACACS+; RFC 2865 RADIUS (client only); RFC 2866 RADIUS Accounting; Secure Sockets Layer (SSL); SSHv1/SSHv2 Secure Shell
BGP	RFC 1997 BGP Communities Attribute; RFC 2918 Route Refresh Capability; RFC 4271 A Border Gateway Protocol 4 (BGP-4); RFC 4456 BGP Route Reflection: An Alternative to Full Mesh Internal BGP (IBGP); RFC 5492 Capabilities Advertisement with BGP-4
Enhedsstyring	RFC 1591 DNS (client); HTML and telnet management
Generelle protokoller	IEEE 802.1ad Q-in-Q; IEEE 802.1AX-2008 Link Aggregation; IEEE 802.1D MAC Bridges; IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.1s Multiple Spanning Trees; IEEE 802.1v VLAN classification by Protocol and Port; IEEE 802.1w Rapid Reconfiguration of Spanning Tree; IEEE 802.3ad Link Aggregation Control Protocol (LACP); IEEE 802.3af Power over Ethernet; IEEE 802.3x Flow Control; RFC 768 UDP; RFC 783 TFTP Protocol (revision 2); RFC 792 ICMP; RFC 793 TCP; RFC 826 ARP; RFC 854 TELNET; RFC 868 Time Protocol; RFC 951 BOOTP; RFC 1058 RIPv1; RFC 1350 TFTP Protocol (revision 2); RFC 1519 CIDR; RFC 1542 BOOTP Extensions; RFC 2030 Simple Network Time Protocol (SNTP) v4; RFC 2131 DHCP; RFC 2453 RIPv2; RFC 2548 (MS-RAS-Vendor only); RFC 3046 DHCP Relay Agent Information Option; RFC 3576 Ext to RADIUS (CoA only); RFC 3768 VRRP; RFC 4675 RADIUS VLAN & Priority; UDLD (Uni-directional Link Detection)
IP Multicast	RFC 3376 IGMPv3 (host joins only); RFC 3973 PIM Dense Mode; RFC 4601 PIM Sparse Mode
IPv6	RFC 1981 IPv6 Path MTU Discovery; RFC 2375 IPv6 Multicast Address Assignments; RFC 2460 IPv6 Specification; RFC 2464 Transmission of IPv6 over Ethernet Networks; RFC 2710 Multicast Listener Discovery (MLD) for IPv6; RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations (Ping only); RFC 3019 MLDv1 MIB; RFC 3315 DHCPv6 (client and relay); RFC 3484 Default Address Selection for IPv6 ; RFC 3587 IPv6 Global Unicast Address Format; RFC 3596 DNS Extension for IPv6; RFC 3810 MLDv2 for IPv6; RFC 4022 MIB for TCP; RFC 4087 IP Tunnel MIB; RFC 4113 MIB for UDP; RFC 4213 Basic Transition Mechanisms for IPv6 Hosts and Routers ; RFC 4251 SSHv6 Architecture; RFC 4252 SSHv6 Authentication; RFC 4253 SSHv6 Transport Layer; RFC 4254 SSHv6 Connection; RFC 4291 IP Version 6 Addressing Architecture ; RFC 4293 MIB for IP; RFC 4294 IPv6 Node Requirements; RFC 4419 Key Exchange for SSH; RFC 4443 ICMPv6; RFC 4541 IGMP & MLD Snooping Switch; RFC 4861 IPv6 Neighbor Discovery; RFC 4862 IPv6 Stateless Address Auto-configuration; RFC 5095 Deprecation of Type 0 Routing Headers in IPv6 ; RFC 5340 OSPFv3 for IPv6; RFC 5453 Reserved IPv6 Interface Identifiers; RFC 5519 Multicast Group Membership Discovery MIB (MLDv2 only) ; RFC 5722 Handling of Overlapping IPv6 Fragments
MIB'er	IEEE 802.1ap (MSTP and STP MIB's only); RFC 1213 MIB II; RFC 1493 Bridge MIB; RFC 1724 RIPv2 MIB; RFC 1850 OSPFv2 MIB; RFC 2021 RMONv2 MIB; RFC 2096 IP Forwarding Table MIB; RFC 2613 SMON MIB; RFC 2618 RADIUS Client MIB; RFC 2620 RADIUS Accounting MIB; RFC 2665 Ethernet-Like-MIB; RFC 2668 802.3 MAU MIB; RFC 2674 802.1p and IEEE 802.1Q Bridge MIB; RFC 2737 Entity MIB (Version 2); RFC 2787 VRRP MIB; RFC 2863 The Interfaces Group MIB; RFC 2925 Ping MIB; RFC 2933 IGMP MIB
Netværksadministration	IEEE 802.1AB Link Layer Discovery Protocol (LLDP); RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events); RFC 3176 sFlow; ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED); SNMPv1/v2c/v3; XRMON
OSPF	RFC 2328 OSPFv2; RFC 3101 OSPF NSSA; RFC 5340 OSPFv3 for IPv6
QoS/Cos	RFC 2474 DiffServ Precedence, including 8 queues/port; RFC 2597 DiffServ Assured Forwarding (AF); RFC 2598 DiffServ Expedited Forwarding (EF)
Sikkerhed	IEEE 802.1X Port Based Network Access Control; RFC 1492 TACACS+; RFC 2865 RADIUS (client only); RFC 2866 RADIUS Accounting; RFC 3579 RADIUS Support For Extensible Authentication Protocol (EAP); Secure Sockets Layer (SSL); SSHv2 Secure Shell
Reaktionstid	100 Mb Latency: < 3.4 µs; 1000 Mb Latency: < 2.9 µs
Overførselshastighed	12.5 million pps
Porte	44 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX); Media Type: Auto-MDIX; Duplex: half or full; 4 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab 1000BASE-T Gigabit Ethernet) with PoE, or an open mini-GBIC slot (for use with mini-GBIC transceivers); 1 RS-232C DB-9 console port; Included
Juridisk ansvarsfraskrivelse
Billeder - juridisk ansvarsfraskrivelse	Product image may differ from actual product
Quickspec
Webadresse til yderligere oplysninger	http://www.hp.com/go/procurve/
Produktmål (med valgfrit efterbehandlingsudstyr, metrisk)
Mindste produktmål (B x D x H)	44.3 x 43.0 x 4.4 cm
Kassens vægt (kasse eller masterkasse)
Vægt	6.1 kg
Garantimuligheder
Garanti	Lifetime, advance replacement, next business day
Processorstik
Hukommelse og processor	Management module : Stackable memory and processor: Freescale PowerPC 8540 @ 666 MHz, 4 MB flash, 128 MB compact flash, 256 MB DDR SDRAM
Batteritype
Strømforsyning	1.6 A / 0.8 A
Strøm	The switch automatically adjusts to any voltage between 100-127 and 200-240 V with either 50 or 60 Hz.
Strømforbrug	136.2 W (maximum)
Strømforbrug (standby)	96 W
Indgangsfrekvens	50/60 Hz
Indgående driftsstrøm	1.6/0.8 A
Strøm	100 -127 VAC / 200 -240 VAC; 50 /60 Hz
Indgangsspænding	100 - 127 / 200 - 240 VAC
Afbrydergrænse
Montering	Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only
Rackmontering	Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only
Formfaktor
Formfaktor	1U height

Selvom vi gør vores bedste for at give fyldestgørende information, så er billederne kun vejledende, og selve varen er ikke nødvendigvis 100% identisk med det afbillede. Produkter kan eksempelvis være vist med ekstraudstyr, ligesom farve og form også kan variere fra det viste. Hvis der er uoverensstemmelse mellem produktoverskrift, beskrivelse og billede, så er det altid produktoverskriften, der gælder. Hvis du er i tvivl, så er du altid velkommen til at kontakte os. Vi tager forbehold for trykfejl, ændring af priser og specifikationer uden varsel.
