| Forbindelsesteknologi | Ledningsført |
| Værtsgrænseflade | PCI Express |
| Grænseflade | Fiber |
| Fiberkanal porte | 2 |
| Fiber optisk strømstik | SFP+ |
| PCI version | 4.0 |
| Maksimal dataoverførselshastighed | 32000 Mbit/s |
| Intern | Ja |
| Komponent til | Server |
| Produktfarve | Sort, Grøn, Rustfrit stål |
| Understøtter hot-plug | Ja |
| Certificering | AS/NZS CISPR22:2009+A1, Class A, Australian EMC Framework (RCM), China RoHS compliant, cUR recognized to CSA 22.2, No. 60950-1-07, EN55022:2010, Class A, EN55024:2010, EN55032:2012, EU (CE Mark), FCC Rules, Part 15, Class A, Industry Canada, ICES-003, Class A, Japan VCCI, Class A, Korea MSIP, Class A, RoHS Compliant (Directive 2011/65/EU), TUV certified to EN60950-1+A11+A1+A12+A2, Taiwan BSMI, Class A, UL recognized to UL60950-1 2nd Edition |
| Kompatible produkter | SR630 (7X01/7X02), SR650 (7X05/7X06), SR635 (7Y98 / 7Y99), SR655 (7Y00 / 7Z01), SR850 (7X18/7X19), SR860 (7X69/7X70), SR950 (7X11/12/13) |
| Kompatible operativsystemer | Red Hat Enterprise Linux 7.6, Red Hat Enterprise Linux 7.7, Red Hat Enterprise Linux 8.0, VMware vSphere Hypervisor (ESXi) 6.7 U1, VMware vSphere Hypervisor (ESXi) 6.7 U2, VMware vSphere Hypervisor (ESXi) 6.7 U3 |
| Understøttede operativsystemer til servere | SUSE Linux Enterprise Server 12, Windows Server 2016, Windows Server 2019 |
| Driftstemperatur (T-T) | 0 - 55 °C |
| Opbevaringstemperatur (T-T) | -20 - 85 °C |
| Relativ luftfugtighed ved drift (H-H) | 5 - 95% |
| Bredde | 69 mm |
| Dybde | 168 mm |
| Maksimal driftstemperatur | 55 °C |
| Harmoniseret systemkode (HS) | 85176990 |
