| HW |
Internal Memory 8 GB, Temperature Sensor, Power Indicator (Standby : Red, Power On : White), Local Key Operation |
| SW |
webOS ver(webOS5.0), Multi-screen (PIP, PBP (2)), ISM Method, HDMI |
| Picture |
Adjust(OLED Light, Brightness, Contrast, Chroma, Sharpness, Tint), Color Temp(VAR Temp./9300K/6500K/5400K/3200K/D65(6504K)/C(6774K)/D-Cinema(6302K)), R/G/B Gain(-100 ~ 100), Transfer Matrix(Auto / BT.709 / BT.601 / BT.2020), Mastering Peak(Auto / 0 / 400 / 540 / 700 / 1000 / 2000 / 3000 / 4000 / 10000), SDI Color Format(Auto / RGB444 / YCbCr444 / YCbCr422 ), SCAN(Zero Scan /Over Scan / Under Scan / Pixel to Pixel), AFD (Active Format Description), Aspect Ratio(Full/16:9/4:3/14:9/13:9/1.85:1/2.35:1), ZOOM(2x, 3x, 4x, 5x), Mono/Blue Only(Off/MonoColor/Blue Color), HDMI IT Content, PictureOptions(Noise Reduction, MPEG Noise Reduction, Black Level, Real Cinema, Motion Eye Care, Dynamic Tone Mapping, Dynamic Contrast, Dynamic Color) |
| Color Space |
Native / DCI-P3 / BT.709 / SMPTE-C / BT.2020 / EBU / Adobe RGB / NTSC |
| EOTF |
User/1.9/2.2/2.4/2.6/BT1886(±0.2)/HDR10 / HLG / Dolby Vision |
| Marker |
Marker(Off/16:9/4:3/14:9/13:9/1.85:1/2.35:1/User Marker 1/User Marker 2/User Marker 3), Safety Area(Off/16:9 95%/16:9 93%/16:9 90%/16:9 88%/16:9 85%/16:9 80%/4:3 95%/4:3 93%/4:3 90%/4:3 88%/4:3 85%/4:3 80%), Center Marker,Marker Thickness, Marker Color, Preset1(Preset1~2) |
| Audio |
Audio Source Selection(SDI1/ SDI 2 / SDI 3 / SDI 4 / SFP+), Audio Level Meter |
| Video Analysis |
Waveform / Vector, HDR/SDR monitoring |
| Advanced |
Profile(1~10), Function Key(F1~5), OnScreen Display, UMD (Under Monitor Display), Input ID,VPID, Information, Control(Key/LED/IR), HDMI Ultra HD Deep Color, OLED Panel Settings(TPC, Pixel Refresher, Screen Shift, Logo Luminance Adjustment, Global Sticky Reduction, Convex Power Control, Uniformity Compensation), Screen Saver(On / Off),Screen Control(I/P Mode, Internal Pattern),Power(No Signal / No IR), Network Settings, Caption(608, 708),PIP/PBP, Gen Lock, Change Device Password, Factory Reset |
