OM46B

• Vivid and visible even in direct sunlight in FHD resolution
• High brightness window displays that deliver flawless colors with 4,000nit
• Slim design that complements the surroundings of any environment
• Robust durability with IP5X-validated dust protection and functionality that mitigates overheating

• Panel
• Diagonal Size 46
• Type VA
• Resolution 1920*1080 (Full HD)
• Pixel Pitch(mm) 0.53x0.53
• Active Display Area(mm) 1018.08(H) x 572.67(V)
• Brightness(Typ.) 4000 nit
• Contrast Ratio 6000:1
• Viewing Angle(H/V) N/A
• Response Time(G-to-G) N/A
• Color Gamut 72%
• Operation Hour 24/7
• Haze 0%
• Connectivity
• Input
• RGB HDMI 2.0 (2)
• Video N/A
• HDCP HDCP2.2
• USB USB 2.0 x 1
• Output
• Video HDMI 2.0
• Audio Stereo mini Jack
• External Control RS232C(in/out), RJ45 (in/out)
• BT/WiFi N/A / Yes
• Power
• Power Supply AC 100 - 240 V, 50/60 Hz
• Power Consumption
• Max[W/h] 350.0
• Typical[W/h] 185※ IEC 62087 measurement standard
• Sleep mode 0.5
• Mechanical Specification
• Dimension (mm)
• Set 1062 x 616.6 x 54.5
• Package 1189 x 757 x 158
• Weight (kg)
• Set 18.2
• Package 23.0
• VESA Mount (mm) 400 x 400
• Bezel Width (mm) 19.9
• Operation
• Operating Temperature 0 ℃ ~ 40 ℃ Humidity 10.0 % ~ 80.0 %
• Feature
• Key Features N/A
• Orientation Landscape / Portrait
• Remote Control N/A
• Special Features H/W : Polarized Sun Glasses Viewable in any direction Auto Brightness Control with Ambient Brightness Sensor Temperature Sensor Clock Battery(80hrs Clock Keeping) Kensington Lock S/W : Auto Source Switching & Recovery RJ45 MDC WiFi Module Embedded
• Internal Player Processor Cortex A72 1.7GHz Quad-Core CPU
• On-Chip Cache Memory N/A
• Clock Speed N/A
• Main Memory Interface N/A
• Graphics N/A
• Storage (FDM) 8GB (3.88GB Occupied by O/S, 4.12GB Available)
• Multimedia N/A
• IO Ports N/A
• Operating System Tizen 5.0 (VDLinux)
• Certification
• Safety 60950-1
• EMC Class A
• IP Rating IP5x
• Accessory
• Included Quick Setup Guide / Warranty Card / Power Cord / Remote Controller + Batteries / External ambient Sensor
• Optional
• Stand N/A
• Mount N/A
• Specialty N/A
• Media Player
• Media Player N/A
