VM55T-U

• 3.5mm (B-to-B) ultra-narrow bezel video wall allows seamless display
• The exceptionally thin cabinet depth provides flexibility to create the exact video wall
• Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content

• Panel
• Diagonal Size 55
• Type IPS
• Resolution 1920*1080 (Full HD)
• Pixel Pitch(mm) 0.63mm(H)*0.63mm(V)
• Active Display Area(mm) 1209.6 * 680.4 mm
• Brightness(Typ.) Max 500 nit
• Contrast Ratio 1200:1
• Viewing Angle(H/V) 178/178
• Response Time(G-to-G) 8ms
• Display Colors 8 bit - 16.7M
• Color Gamut 72%
• Operation Hour 24/7
• Haze 25%
• Display
• Dynamic C/R 45,000:1
• H-Scanning Frequency 62.7kHz ~ 72.3kHz
• V-Scanning Frequency 57Hz ~ 63Hz
• Maximum Pixel Frequency 82MHz
• Connectivity
• Input
• RGB DVI-D, Display Port 1.2
• Video HDMI 2.0 (2)
• HDCP HDCP 2.2
• Audio Stereo mini Jack
• USB Only F/W upgrade
• Output
• RGB DP1.2(Loop-out)
• Audio Stereo mini Jack
• External Control RS232C(in/out), RJ45
• External Sensor Detachable type(IR)
• Power
• Type Internal
• Power Supply AC 100 - 240 V, 50/60 Hz
• Power Consumption
• Max[W/h] 220
• Typical[W/h] 136
• BTU(Max) 825.0
• Sleep mode less than 0.5W
• Off mode less than 0.5W
• Mechanical Specification
• Dimension (mm)
• Set 1213.5 x 684.3 x 73.1
• Package 1398 x 844 x 257
• Weight (kg)
• Set 21.2kg
• Package 28.8kg
• VESA Mount (mm) 600 * 400 (mm)
• Bezel Width (mm) 2.3mm(U/L), 1.2mm(R/B)
• Operation
• Operating Temperature 0 ℃ ~ 40 ℃ Humidity 10 % ~ 80 %
• Feature
• Key Features Ultra Narrow Bezel
• Orientation N/A
• Remote Control N/A
• Special Features ACM Support(Advanced Color Management), Auto Source Switching & Recovery, Haze 28%, Temperature Sensor, RS232C/RJ45 MDC, Plug and Play (DDC2B), Video Wall(15x15(OSD)), Video Wall Daisy Chain(10x10), Pivot Display, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Smart F/W update, Clock Battery(168hrs Clock Keeping) IP5X tested, EMC Class A, Center IR
• Certification
• Safety UL (USA) : UL 60950-1 CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1 NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : IEC60950-1 GOST (Russia) : IEC60950-1, EN55022 SIQ (Slovenia) : IEC60950-1, EN55022 PCBC (Poland) : IEC60590-1, EN55022 NOM (Mexico) : NOM-019-SCFI-1993 IRAM (Argentina) :IEC60950-1 SASO (Saudi Arabia) : IEC60950-1
• EMC FCC (USA) FCC Part 15, Subpart B class B CE (Europe) EN55022, EN55024 VCCI (Japan) VCCI CISPR32:2016 KCC (Korea) :KN32, KN35 BSMI (Taiwan) : CNS13438 (CISPR22) C-Tick (Australia) : AS/NZS CISPR32:2015 CCC(China) :GB9254-2008, GB17625.1-2012
• IP Rating IP5X
• Accessory
• Included Quick Setup Guide, Warranty Card, DP cable, stereo to DB9 cable, Power Cord, Remote Controller, Batteries, External IR
• Optional
• Stand N/A
• Mount WMN-55VD
• Specialty N/A
• Media Player
• Media Player Signage player box
